A358 WELDED STAINLESS STEEL INDUSTRIAL PIPE
Standard: ASTM A312;ASTM A269;ASTM A789:ASTM A790 ect
Material:TP304,TP304L,TP304H,TP316,TP316L.TP316Ti.TP309STP310S,TP321,TP321H,TP347,TP347H,etc
Outer Diameter:5.80mm - 2032mm ( 0.23” to 80”) WallThickness: 0.25mm - 28mm ( 0.01” to 1.125”)
Length: Normally fixed length 6mcan as per customer's requirement
Category: Welded Pipe
Standard: ASTM A312;ASTM A269;ASTM A789:ASTM A790 ect
Material:TP304,TP304L,TP304H,TP316,TP316L.TP316Ti.TP309STP310S,TP321,TP321H,TP347,TP347H,etc
Outer Diameter:5.80mm - 2032mm ( 0.23” to 80”) WallThickness: 0.25mm - 28mm ( 0.01” to 1.125”)
Length: Normally fixed length 6mcan as per customer's requirement
Category: Welded Pipe
Standard: ASTM A312;ASTM A269;ASTM A789:ASTM A790 ect
Material:TP304,TP304L,TP304H,TP316,TP316L.TP316Ti.TP309STP310S,TP321,TP321H,TP347,TP347H,etc
Outer Diameter:5.80mm - 2032mm ( 0.23” to 80”) WallThickness: 0.25mm - 28mm ( 0.01” to 1.125”)
Length: Normally fixed length 6mcan as per customer's requirement
Category: Welded Pipe
ASTM A358 steel pipe is a type of electric-fusion-welded austenitic stainless steel pipe suitable for high-temperature service and general applications.
The material properties of ASTM A358 pipe include high strength, resistance to corrosion and high temperatures, and low maintenance.
It is made with electric fusion welding, a process that offers high-cost efficiency.
The A358 is resistant to chloride ion corrosion due to the presence of molybdenum in the composition.
The manufacturing process of ASTM A358 steel pipe involves electric fusion welding, a process that employs filler metal in all passes.
The pipes are double welded by processes employing filler metal in all passes and are completely radiographed.
ASTM A358 pipe specifications cover five classes of pipe, including CL1, CL2, CL3, CL4, and CL5.
ASTM A358 Chemical Composition
|
Standard & Grade |
Chemical Composition (%) |
|||||||||
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
|||
|
ASTM A213 A312 |
TP304 |
≤0.080 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
8.0~11.0 |
18.0~20.0 |
|
|
|
TP304L |
≤0.035 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
8.0~13.0 |
18.0~20.0 |
|
||
|
TP316 |
≤0.080 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
10.0~14.0 |
16.0~18.0 |
2.0~3.0 |
||
|
TP316L |
≤0.035 |
≤1.00 |
≤2.00 |
≤0.045 |
≤0.030 |
10.0~14.0 |
16.0~18.0 |
2.0~3.0 |
||
Stainless Steel Solution Heat Treating Condition
|
ASTM A358 |
||
|
Grade |
Annealing Requirement |
|
|
TP304 |
1040℃min., Water Quenching |
|
|
TP304L |
||
|
TP316 |
||
|
TP316L |
||
ASTM A358 Stainless Steel Pipe Dimension
|
Materials |
Outer Diameter |
Wall Thickness |
Length |
Standard |
|
Austenitic Duplex Steel Nickel Alloy Cobalt Alloy Ferrite |
8-711mm DN6-DN700 1/8"-28" |
1-50mm Sch5s -SchXXS |
≤12m |
ASTM-A312 ASTM-A790 ASTM-A269 ASTM-B167/163 ASTM-B444 ASTM-B622 ASTM-B423 ... |
|
Item Standard |
Outside Diameter |
Thickness |
Length |
|||
|
ASTM A358 |
Based on circumferential measurement ± 0.5% Difference between major and minor outside diameters 1% |
- 0.3mm |
L≤7.3m +6.0mm - 0mm |
|||
|
ASTM A312/A312M,A358/A358M A778/A778M,B36.19M/B36.10M |
Stainless Steel Welded pipes |
|||||||||
|
Nominal Diameter NPS |
Outside Diameter (mm) |
Nominal Wall Thickness (mm) |
||||||||
|
ASME B36.19M |
ASME B36.10M |
|||||||||
|
SCH-5s |
SCH-10s |
SCH-40s |
SCH-80s |
SCH-5 |
SCH-10 |
SCH-20 |
STD |
XS |
||
|
1/4 |
13,72 |
- |
1,65 |
2,24 |
3,02 |
- |
1,65 |
- |
2,24 |
3,02 |
|
3/8 |
17,15 |
- |
1,65 |
2,31 |
3,2 |
- |
1,65 |
- |
2,31 |
3,2 |
|
1/2 |
21,34 |
1,65 |
2,11 |
2,77 |
3,73 |
1,65 |
2,11 |
- |
2,77 |
3,73 |
|
3/4 |
26,67 |
1,65 |
2,11 |
2,87 |
3,91 |
1,65 |
2,11 |
- |
2,87 |
3,91 |
|
1 |
33,4 |
1,65 |
2,77 |
3,38 |
4,55 |
1,65 |
2,77 |
- |
3,38 |
4,55 |
|
1 1/4 |
42,16 |
1,65 |
2,77 |
3,56 |
4,85 |
1,65 |
2,77 |
- |
3,56 |
4,85 |
|
1 1/2 |
48,26 |
1,65 |
2,77 |
3,68 |
5,08 |
1,65 |
2,77 |
- |
3,68 |
5,08 |
|
2 |
60,33 |
1,65 |
2,77 |
3,91 |
5,54 |
1,65 |
2,77 |
- |
3,91 |
5,54 |
|
2 1/2 |
73,03 |
2,11 |
3,05 |
5,16 |
7,01 |
2,11 |
3,05 |
- |
5,16 |
7,01 |
|
3 |
88,9 |
2,11 |
3,05 |
5,49 |
7,62 |
2,11 |
3,05 |
- |
5,49 |
7,62 |
|
31/2 |
101,6 |
2,11 |
3,05 |
5,74 |
8,08 |
2,11 |
3,05 |
- |
5,74 |
8,08 |
|
4 |
114,3 |
2,11 |
3,05 |
6,02 |
8,56 |
2,11 |
3,05 |
- |
6,02 |
8,56 |
|
5 |
141,3 |
2,77 |
3,4 |
6,55 |
9,53 |
2,77 |
3,4 |
- |
6,55 |
9,53 |
|
6 |
168,28 |
2,77 |
3,4 |
7,11 |
10,97 |
2,77 |
3,4 |
- |
7,11 |
10,97 |
|
8 |
219,08 |
2,77 |
3,76 |
8,18 |
12,7 |
2,77 |
3,76 |
6,35 |
8,18 |
12,7 |
|
10 |
273,05 |
3,4 |
4,19 |
9,27 |
12,7 |
3,4 |
4,19 |
6,35 |
9,27 |
12,7 |
|
12 |
323,85 |
3,96 |
4,57 |
9,53 |
12,7 |
3,96 |
4,57 |
6,35 |
9,53 |
12,7 |
|
14 |
355,6 |
3,96 |
4,78 |
9,53 |
12,7 |
3,96 |
6,35 |
7,92 |
9,53 |
12,7 |
|
16 |
406,4 |
4,19 |
4,78 |
9,53 |
12,7 |
4,19 |
6,35 |
7,92 |
9,53 |
12,7 |
|
18 |
457,2 |
4,19 |
4,78 |
9,53 |
12,7 |
4,19 |
6,35 |
7,92 |
9,53 |
12,7 |
|
20 |
508 |
4,78 |
5,54 |
9,53 |
12,7 |
4,78 |
6,35 |
9,53 |
9,53 |
12,7 |
|
22 |
558,8 |
4,78 |
5,54 |
- |
- |
4,78 |
6,35 |
9,53 |
9,53 |
12,7 |
|
24 |
609,6 |
5,54 |
6,35 |
9,53 |
12,7 |
5,54 |
6,35 |
9,53 |
9,53 |
12,7 |
|
26 |
660,4 |
- |
- |
- |
- |
- |
7,92 |
12,7 |
9,53 |
12,7 |
|
28 |
711,2 |
- |
- |
- |
- |
- |
7,92 |
12,7 |
9,53 |
12,7 |
|
30 |
762 |
6,35 |
7,92 |
- |
- |
6,35 |
7,92 |
12,7 |
9,53 |
12,7 |
|
32 l 84 |
812.8 l 2133.6 |
Thickness: 6.35~30mm |
||||||||
Specifications
-
1 . For fluid and gas transport
2 . Structure and machining
-
1 . Superior surface finish
2 . Better mechanical property
3 .More precise dimension
4 . Perfect inspection method and inspection equipment
-
We offer product with tolerance complies with the norm (Specific tolerance requirement is possible. Please contact our sales specialists.)
